          首頁 >> 產品中心 >>S102系列 >>YC-S102/2C雙色全自動絲印機 >> 雙色全自動絲印機2 COLOR AUTOMATIC CARTRIDGE SCREEN PRINTING MACHINE
          详细说明

          雙色全自動絲印機2 COLOR AUTOMATIC CARTRIDGE SCREEN PRINTING MACHINE

          最大印刷面積

          Maximum printing area

          320mm×250mm

          最大網框尺寸

          Max. screen frame size

          550mm×350mm

          圓形瓶直徑

          Min. and max. diameter of cylinderical container

          Ø10mm-Ø25mm

          最快印刷速度

          Maximum printing speed

          5000pcs/hr (取決于產品大小以及印刷尺寸)

          (depends on dimension of the printed bottles)

          電源要求

          Power requirement

          380V  3phase  50/60Hz  7KW  (每一個顏色 each color)

          氣源要求

          Air consumption

          6 bar(50L/min)

          機器重量

          Weight

          2700KG



          收藏
          • 产品说明



                   專為容器表面絲印而設計,可以滿足圓形、橢圓形、方形等不同形狀的容器自動印刷

                   It's specially designed for containers surface screen printing. It can auto screen print round, oval, square and other shapes of

                   containers.

                   主要適用于化妝品、食品、醫藥、化工等不同領域的印刷包裝。

                   Mainly suit for cosmetics, beverage, food, medicine and other fields screen printing.

                   集成自動上料、自動選向、表面火焰處理、自動定位及UV固化等諸多功能。

                   It integrate automatic loading, auto-orientation, flaming treatment, automatic positioning, UV curing and other functions.

                   整機采用單元模塊化設計,機械凸輪傳動,PLC控制,套色精準,性能穩定可靠。

                   Whole machine adopts unit modular design, mechanical CAM drive, PLC control, high precision overprinting, stable and reliable

                   performance.

                  集成自動上下料,產品表面靜電除塵、火焰處理,自動定位印刷及UV固化等諸多功能。

                   It integrates automatic loading&unloading, surface treatment, auto matic positioning, UV curing and other functions.

                 可根據生產需要自由選擇由單色至多色,最高可拓展至六色

                   Customers can choose one color to multi colors,The maximum can be extended to six colors.
